The Conical Mandrel Tester is used to determine the extensibility of paint coatings on metal panels clamped in position and formed round the conical mandrel by rotation of the roller frame. The panels are then examined to evaluate crack resistance and detachment from the metal substrate. This instrument allows easy identification of any coating failure at a specified diameter, over part or entire mandrel length. Supplied in a sturdy protective case with full user instructions. To see the instrument being demonstrated, click on the "Video" tab
Conical Mandrel Tester
Conical Mandrel Tester to determine the extensibility of paint coatings
Relevant Standards: ASTM D 522, D1737, BS 3900 E11 and ISO 6860
Conical Mandrel Tester - Ref: T01-710100
Total:
Each:
Each:
Delivery 3-4 working days
- Relevant Standards: ASTM D 522, D1737, BS 3900 E11 and ISO 6860
- Dimensions of conical mandrel: Large end: 38±0.1mm Small end: 3.1±0.1mm Length: 203±0.3 mm
- Clamping device makes fixing sample simple and easy
- Suitable test panel size parameters: Length ≤ 150mm Width ≤ 100mm Thickness ≤ 0.8mm
- Overall dimensions: 300×120×83 mm (Lx W x H)
- Weight: 7kg
Conical Mandrel Tester
